High pressure self-priming pump for coffee machine

Coffee Machine Pump

High pressure self-priming pump for coffee machine

A solenoid pump uses a magnetic field and current interaction, the current through the electromagnetic winding, the formation of an altering field, pushes the plunger to the overlying movement, generates pressure, and promotes fluid output.
  • Item No :

    EPL for Coffee Machine
  • Custom :

    Accept
  • MOQ :

    3000
  • Warranty :

    2 years
  • Port :

    Shenzhen
  • Lead time :

    35 days
  • Payment Terms :

    T/T, L/C
  • Samples Time :

    One Week
  • Certification :

    UL, CE, TUV, VDE, ISO9001, ISO14001

High Pressure Self-Priming Pump for Coffee Machine



Technical Concept

An solenoid pump uses a magnetic field and current interation, the current through the eletromagnetic winding, the formation of an altering field, pushes the plunger to the overlying movement, generates pressure, and promotes fluid output.



Product Performance

Room temperature: 25℃(Testing Condition)

Ideal fluid: water at 25℃

Self-priming at 0 bar

Reinforced Insulation

Integrated diode(Optional)

Thermal cutout pocket

Suitable to dry-use only during priming



Mechanical Assembly

It is easy and reliable to install the fixed terminal rubble cover at any position.

If fixed rubble positioning is used, noise can be reduced.

Quick mount type, 6.3×0.88mm terminals, enough for a tight and reliable connection.

The rubble cover seals the water inlet end and water outlet end to prevent any particles from entering the pump body.



Typical Appliances

Coffee machines, steam cleaners, steam irons, garment steamer, and spraying equipment.



Products Specification



Type Region Voltage/Frequency Region Voltage/Frequency
AC USA 120V 60Hz China 220V 50Hz
Europe 220-240V 50Hz Taiwan

110V 60Hz

Japan 110V 50/60Hz Korea 220V 60Hz





Voltage 24-240V/50-60Hz Max. Pressure 2.5~20Bar
Power 53W Flow Rate 500~2300 ml
Ideal Fluid Pure Water Noise <55dB
Room Temperature At 25℃ Service Life Over 500Hrs
Ambient Temperature 0~60℃

Dry Pumping Function

Installation Method

Not Available

Not Available

Working Mode ON/OFF=2/1(min)
Insulation Level Class H/F
Intergrate Diode R2000 2000V





Outline Drawing Ref.





Torque Curve







Application Display
